BSM 140 DUAL

The BSM 140 DUAL is designed for use in situations where 2 batteries are used; for example in boats, campers and caravans. The Battery separator is a microprocessor controlled high capacity mechanical switch with vibration (i.e. motion) detection. Since every vehicle (EURO 5/6 engines) has its own vibration frequency and amplitude, the user can set the sensitivity of the BSM.

✓ Innovatief productontwerp
✓ ISO 9001-2015 gecertificeerd
✓ Strikte kwaliteitscontrole

Offerte Binnen 24 Uur

Categorie:

Beschrijving

Input Voltage Automatic detection 12/24 V
Output Voltage >11.8 or >23.6 VDC
Dimensions 46 x 46 x 80 mm
Output 140 A
Fuse Rating n/a
Weight 0,15 Kgs
  • Microprocessor controlled
  • Motor status detection through vibration
  • Prevents excessive discharging of the starter battery
  • Automatic detection for 12 or 24 Vdc system
  • Easy to install – does not require changing the existing circuit of the alternator EURO 5/6
  • Bidirectional
  • No voltage drop
  • 2 year warranty
