MPC-20
A unique product; 1 product for 3 different applications. This Multi Purpose Converter is carrying a DC-DC voltage converter, 3-step 24Vdc-12Vdc batterycharger and 12/24 Vdc dimmerfunction in one hand. The MPC-20 is having common ground for easy installation, remote switch and temperature sensor option. In case the main battery( bank) is charged, automatically the 12Vdc service battery(bank) will be charged according to a real charge algorithm. Your LED light can be easily dimmed by a pulseswitch. The MPC-20 is the best allround DC-converter with an excellent price performance ratio.
✓ Innovative product design
✓ ISO 9001-2015 certified
✓ Strict Quality Control
Quotation Within 24 Hours
- Description
- Product benefits
- Documentation
Description
0,90 kgs
| Input Voltage | 18-35Vdc (depends on the setting) |
| Output Voltage | 12-15Vdc (depends on the setting) |
| Dimensions | 190x123x66 mm |
| Output | 20 Amp |
| Fuse Rating | n/a |
| Weight | 0,90 kgs |
- Advanced switchmode design
- 24-12Vdc DC-DC converter
- 12 or 24Vdc dimmerfunction
- 3-STEP charge algortihm batterycharger
- Remote switch option
- Temperature sensor option
- Compact and light weight
- European product
- 2 year warranty
| Language | File | Type |
| n.a. | MPC-20.jpg | Image |
 |
MPC-20_slicksheet | Specifications |
 |
Bedienungsanleitung MPC-20 | Manual |
 |
Gebruiksaanwijzing MPC-20 | Manual |
| |
Manual MPC-20 | Manual |
 |
Mode D’Emploi MPC-20 | Manual |
| Manual |
