PSI 1000-24
This highly efficient DC-AC inverter converts 24 Volts DC to 1000 Watts of pure sine wave AC power at 230 Volts, 50Hz. The unit is having heavy duty screw M8 connection. Features include overload protection, low battery alarm / shut down, low idle power draw of less than 0.5 Amps. AC power is available from a single standard 2x VDE European outlet, accessible on the front panel. Including remote control and cable.
✓ Innovative product design
✓ ISO 9001-2015 certified
✓ Strict Quality Control
Quotation Within 24 Hours
- Description
- Product benefits
- Documentation
Description
| Input Voltage | 21.0 – 31.2 VDC (± 0.4 VDC) |
| Output Voltage | 225VAC (± 5VAC) |
| Dimensions | 222 x 284 x 89 mm |
| Output | 1000 Watts |
| Fuse Rating | 2x 40A in parallel (Automotive Blade Fuses, Type ATO/ATC, 32 VDC) |
| Weight | 2.4 Kgs |
- Pure sine wave output voltage
- High efficiency
- Switch-mode design
- Remote control enclosed
- 230 VAC output from 12 VDC input
- 50Hz
- LED indicators for power and protections
- Protections: input low voltage, input over voltage, over temperature, over load, short circuit
- Low idle power draw
- Remote input
- ECE-10R approval
- 2 year warranty
| Language | File | Type |
| n.a. | PSI-1000 | Image |
 |
PSI-1000-24_slicksheet | Specification |
 |
Bedienungsanleitung PSI 1000-1500-2000-3000 | Manual |
 |
Gebruiksaanwijzing PSI 1000-1500-2000-3000 | Manual |
|
Manual PSI 1000-1500-2000-3000 | Manual |
 |
Manual-del-Propietario-PSI-1000_1500_2000_3000 | Manual |
 |
Mode-DEmploi-PSI-1000-1500-2000-3000 | Manual |
