WSC-2440Li
This advanced fully automatic 4-stage 40 Amp battery charger is ideal for charging all types of 24 Volt lead-acid batteries ( Flooded / Absorbed Glass Mat (AGM) / Gel Cell), LI-Ion from a 115/230 V, 50/60 Hz AC source. A DIP switch setting can be used to convert to a two stage algorithm, in order to charge batteries connected to a DC load (DC UPS). The unit can also be used as a DC Power Supply. Features include overload and short circuit protection. The unit allows charging of up to 3 separate battery banks.
✓ Innovative product design
✓ ISO 9001-2015 certified
✓ Strict Quality Control
Quotation Within 24 Hours
- Description
- Product benefits
- Documentation
Description
Input Voltage | 100-240 VAC |
Output Voltage | 29.6-27 VDC for LEAD ACID and 29.2-28.4 for LITHIUM |
Dimensions | 327 x 220 x 75 mm |
Output | 0-40 Amps |
Fuse Rating | n/a |
Weight | 3 Kgs |
- Wide input range 100-240Vac / 50/60Hz
- Charger/ Power supply function
- 3 different Lithium charging settings (CC/CV)
- Pre-charge for waking up the lithiuimbattery
- Adjustable charging current (40,35,30 or 27.5A)
- Power factor correction 0.97
- Half power mode function
- Fan speed controlled
- Slim line design
- Light Weight
- High Efficiency >90%
- 2 year warranty
Language | File | Type |
n.a. | WSC-2440Li.png | Image |
WSC-2440Li_slicksheet | Specifications | |
Bedienungsanleitung-WSC-1250_1280_2425_2440_4820Li.pdf | Manual | |
Gebruiksaanwijzing-WSC-1250_1280_2425_2440_4820Li.pdf | Manual | |
Manual-del-Propietario-WSC-1250_1280_2425_2440_4820Li.pdf | Manual | |
Manual-WSC-1250_1280_2425_2440_4820Li.pdf | Manual | |
Mode-DEmploi-WSC-1250_1280_2425_2440_4820Li.pdf | Manual |
